VISTA RISE
3-in-1 LoRaWAN CO2 sensor: CO₂, temperature and humidity with a traffic-light indicator
VISTA RISE is a battery-powered LoRaWAN CO2 sensor that measures carbon dioxide (CO₂) concentration, temperature and relative humidity to show how well occupied rooms are ventilated. Its green, amber and red indicator light tells occupants at a glance when it is time to let in fresh air.
Data is sent wirelessly over LoRaWAN (EU868, the frequency plan used in the UK and Ireland) for remote monitoring in NAVIXIS or integration into your Building Management System (BMS) as BACnet points via a compatible gateway.
Designed for offices, schools, hotels and housing, VISTA RISE measures CO₂ from 0 to 5,000 ppm, offers up to 10 years* of battery life and is configured contactlessly by NFC. CE and UKCA marked.
-
CO2 monitoring
CO₂ is measured every 5 minutes and a green, amber and red indicator light shows when rooms need ventilating.
-
Up to 10 years of battery life*
One replaceable CR123 lithium battery to minimise maintenance.
-
Wireless connectivity
LoRaWAN for remote monitoring and BMS integration, plus L2D1 direct device-to-device communication with compatible Nexelec products.
-
Temperature
-
Humidity
-
CO2
-
LoRaWAN
-
L2D1
Measure CO2. Communicate locally. Monitor remotely.
VISTA RISE combines CO₂, temperature and humidity monitoring, long battery life, local device-to-device communication and remote monitoring to simplify the running of connected buildings.
-
Long battery life to limit battery changes and reduce maintenance visits
-
Direct radio communication with compatible Nexelec devices, without a gateway or LoRaWAN network
-
Sensor firmware can be updated over LoRaWAN, with no site visit needed
-
Quick, simple set-up from a smartphone to speed up on-site deployment
LoRaWAN CO2 sensor for indoor air quality and building management systems
In buildings, CO₂ concentration is a practical indicator of how well occupied spaces are ventilated. Combined with temperature and humidity, it gives a clearer picture of indoor conditions and helps identify rooms that need attention.
VISTA RISE brings these three measurements together in a 3-in-1 LoRaWAN environmental sensor. The data is transmitted wirelessly and can be centralised in a monitoring platform or integrated into the Building Management System (BMS), for example as BACnet points via a compatible gateway.
This information helps control heating, ventilation and air conditioning (HVAC) so that systems respond to actual conditions in the building, supporting both indoor air quality and energy efficiency.
Monitor CO2 at a glance with a traffic-light indicator
VISTA RISE measures carbon dioxide every 5 minutes and alerts occupants visually to changes in indoor air quality.
Its green, amber and red indicator light makes it easy to see when a room needs fresh air, helping to build good ventilation habits in offices, meeting rooms, classrooms and other shared spaces.
In the UK, HSE guidance states that CO₂ levels consistently above 1,500 ppm in an occupied room indicate poor ventilation, and BB101 sets CO₂ criteria for teaching spaces in schools in England. VISTA RISE helps you monitor CO₂ against these benchmarks; on its own, it does not demonstrate compliance with building or ventilation requirements.
Indicator light
The Green / Orange / Red indicator changes with the CO2 level and alerts you when it's time to ventilate to renew the indoor air.
CO2 monitoring for indoor air quality
CO2 readings help identify when ventilation may need attention. CO2 is an indicator of ventilation conditions, rather than a measurement of every indoor air pollutant. Measurement intervals depend on the configured settings.
CO2 measurement and calibration
CO2 readings support the assessment of indoor ventilation conditions. Follow the product documentation for calibration procedures and measurement settings; measurement performance does not establish compliance with local building requirements.
CO2 monitoring for ventilation decisions
Direct CO2 readings help inform ventilation decisions. Product measurement capabilities do not by themselves establish compliance with UK or Irish building or ventilation requirements; assess the complete installation and applicable local guidance.
Three measurements to understand indoor conditions
VISTA RISE combines CO₂, temperature and humidity measurement in a single 3-in-1 LoRaWAN sensor.
Together, this data lets you track air exchange, monitor thermal comfort and better understand indoor conditions in commercial buildings, schools and multi-occupancy housing.
Carbon dioxide (CO2)
CO₂ measurement from 0 to 5,000 ppm to track levels in occupied spaces and identify ventilation needs
Temperature
Temperature measurement with ±0.2 °C accuracy to monitor thermal conditions and support heating and cooling control
Humidity
Relative humidity measurement with ±2 % RH accuracy to monitor indoor conditions and help maintain a comfortable environment
L2D1: direct device-to-device wireless communication between Nexelec products
VISTA RISE incorporates Nexelec’s L2D1 radio protocol, which enables direct, device-to-device (D2D) local communication between compatible products.
This link works independently of the LoRaWAN infrastructure and needs no gateway for local communication between paired devices.
VISTA RISE therefore offers two communication options: L2D1 for direct exchanges between compatible devices, and LoRaWAN for remote data collection.
Direct local communication
VISTA RISE communicates directly with compatible Nexelec devices (device-to-device)
Local L2D1 link without a gateway
The local L2D1 link communicates directly with compatible Nexelec devices. Remote LoRaWAN monitoring and BMS integration require the appropriate network infrastructure and a compatible gateway.
Without a LoRaWAN network
L2D1 communications remain available locally, without going through the LoRaWAN network
FUOTA V2 remote firmware updates – no site visit needed
VISTA RISE can receive remote firmware updates over the LoRaWAN network using FUOTA V2 (Firmware Update Over The Air), a mechanism standardised by the LoRa Alliance. Your installed base can benefit from fixes, improvements and new features without routine site visits.
With cyber threats targeting connected devices on the rise, firmware updates play a critical role in smart building cybersecurity. FUOTA V2 makes it possible to deploy security patches remotely, remediate potential vulnerabilities and keep devices up to date throughout their service life.
Based on an open standard, FUOTA V2 works with the many LoRaWAN infrastructures and solutions on the market that support it, with no lock-in to a proprietary ecosystem.
Remote updates help strengthen IoT device security, extend the operational life of VISTA RISE and simplify maintenance of large-scale deployments.
Firmware improvements
Supported firmware fixes and improvements can be deployed through FUOTA V2 when updates are made available.
Open standard
FUOTA V2 follows a LoRa Alliance specification. Remote firmware updates require compatible LoRaWAN infrastructure that supports FUOTA V2.
Simplified maintenance
Remote firmware updates over compatible LoRaWAN infrastructure help minimise on-site maintenance visits.
Up to 10 years* of battery life for minimal maintenance
Powered by a single replaceable CR123 lithium battery, VISTA RISE offers up to 10 years* of battery life, depending on settings and conditions of use.
Its low power consumption extends the time between battery changes and reduces maintenance visits – particularly valuable when deploying large numbers of CO2 sensors across commercial buildings, schools and multi-occupancy housing.
One replaceable CR123 lithium battery
A replaceable CR123 lithium battery powers the sensor. Follow the product instructions when replacing the battery.
Up to 10 years of battery life
Battery life depends on configuration, measurement and transmission settings, network conditions and use; it is not guaranteed.
Fewer maintenance visits
Long battery life can reduce the frequency of battery replacement visits in occupied buildings.
Controlled Maintenance
Battery life suitable for large-scale deployments
Quick, easy installation in any building
VISTA RISE is designed to make CO2 sensors simple to deploy indoors, whether in a single room or across several buildings.
Its compact design allows discreet wall mounting with no mains power or communication cabling.
The sensor can be fixed with screws and wall plugs or with the adhesive pad supplied. Its lockable base, anti-theft screw and tamper detection help keep the installation secure.
Reinforced adhesive
Thick adhesive suitable for smooth and rough surfaces, providing long-lasting adhesion and requiring minimal maintenance
Mounting with screws and wall plugs
Wall mounting with screws and wall plugs provides a secure fixing. Select suitable fixings for the wall material and follow the installation instructions.
Anti-theft protection
Lockable base with anti-theft screws
Tamper detection
An alert is triggered if the product is removed from its mounting base.
NAVIXIS: building-wide monitoring platform
With NAVIXIS, Nexelec’s IoT platform, the data collected by VISTA RISE is centralised and available remotely to simplify building management.
The platform lets you track devices, view CO₂, temperature and humidity readings and set threshold alerts to understand how spaces are used.
For facilities managers, estates teams and building operators, NAVIXIS makes it easier to monitor sites, analyse indoor air quality data and optimise energy consumption over time.
Connect and control your equipment
Facilitates remote management and control of IoT devices and LoRaWAN gateways
Dashboard and graphical data display
Provides an intuitive interface for monitoring key indicators in real time and making it easier to interpret the data collected
Real-time alerts or alerts triggered by thresholds
Notifies users immediately when a critical event occurs or a predefined value is exceeded
Data export and exchange
API connection, webhook notifications and simple data export in .pdf or .csv format
User rights management
Access control to ensure secure and appropriate use of the platform's functionalities
Fast NFC configuration for simple deployment
VISTA RISE features contactless NFC technology, so the sensor’s settings can be configured from a smartphone.
Local configuration makes it easy to tailor settings, such as measurement and transmission intervals and the indicator light, to each environment, and simplifies commissioning.
VISTA RISE also includes an instant measurement function, triggered automatically when the sensor is clipped onto its base or when the function button is pressed. Installers can check straight away that the sensor is working, without waiting for the next scheduled measurement.
NFC Settings
Contactless adjustments via a smartphone
Customisable settings
Adjust measurement and transmission intervals and indicator lights to suit the building and deployment.
Without power
NFC configuration directly through the packaging, without unpacking the sensor or using its battery
Specifications
-
Temperature
Resolution: 0.1 °C
Accuracy: ±0.2 °C
Measurement range: -30 °C to +70 °C
-
Humidity
Resolution: 0.5 % RH
Accuracy: ±2 % RH
Measurement range: 0–100 % RH
-
Carbon dioxide (CO2)
Resolution: 1 ppm
Accuracy: ±(50 ppm + 3 % of reading)
Measurement range: 0–5,000 ppm
Features
-
Connectivity
-
-
Power supply
1 replaceable CR123 lithium battery
-
Dimensions
28 x 66 mm
-
Operating conditions
Indoor use
Temperature: -20 °C to +50 °C
Humidity: 0–99 % RH (non-condensing)
-
Warranty
2 years*
-
Certifications
-
-
What’s in the box
VISTA RISE sensor
1 CR123 lithium battery
Mounting base
Screws and wall plugs
Adhesive pad
References
| Reference | LoRaWAN | Battery life | Colour |
|---|---|---|---|
| X450LS | EU868 | Up to 10 years* | White |
| X450LS_BCK | EU868 | Up to 10 years* | Black |
Use cases: healthier, better-ventilated buildings
Monitor indoor air quality with CO₂, temperature and humidity data to improve occupant comfort and fine-tune ventilation
Monitor CO₂ classroom by classroom and use temperature and humidity data to understand indoor conditions and support a healthier learning environment
Centrally monitor CO₂, temperature and humidity with a compact, battery-powered sensor to keep guest rooms and shared spaces comfortable
Remotely collect CO₂, temperature and humidity data to help identify poorly ventilated homes and conditions linked to condensation, damp and mould, and centralise the information needed to manage your housing stock
A connected CO2 sensor for building management systems (BMS/BACnet)
VISTA RISE is a 3-in-1 LoRaWAN CO2 sensor that measures carbon dioxide concentration, temperature and humidity. Using LoRaWAN wireless communication, it collects this data remotely for integration into a Building Management System (BMS).
Paired with a compatible LoRaWAN-to-BACnet gateway such as Nexelec MASTER PRO or MASTER CORE, the measurements can be converted into BACnet/IP points and used by controllers and building management systems.
This supports centralised control of building services, in particular to adjust ventilation, heating and air conditioning to indoor conditions – for example increasing the fresh-air supply when CO₂ levels rise.
VISTA RISE makes it easy to add large numbers of measurement points without additional communication cabling. NFC configuration, FUOTA V2 updates and up to 10 years* of battery life make large-scale sensor networks straightforward to install and maintain.
If you also need occupancy and light level data, VISTA WAVE adds PIR presence detection and light measurement to CO₂, temperature and humidity in a 5-in-1 LoRaWAN sensor.
Available in black or white
VISTA RISE is available in two colours, black and white, to suit the look and practical requirements of any interior.
With its compact, minimalist design, this 3-in-1 LoRaWAN CO2 sensor blends discreetly into offices, meeting rooms, schools, hotels and public buildings while measuring carbon dioxide (CO₂), temperature and humidity.
A sensor built to last
VISTA RISE reflects Nexelec’s commitment to more responsible electronics and to equipment designed to serve buildings over the long term. Nexelec’s CSR approach is recognised by an EcoVadis Bronze medal.
Its replaceable lithium battery, remote firmware updates and simplified maintenance all help extend its service life.
Its largely recyclable design also helps limit the environmental impact of the equipment.
Designed to blend into interior spaces
With its compact size and understated design, VISTA RISE fits easily into homes, hotels, offices and multi-occupancy buildings.
It can be placed freely or wall-mounted to take measurements in the right spot, without interfering with the everyday use of the room.
Frequently Asked Questions
Our experts answer your questions
VISTA RISE by Nexelec is a 3-in-1 LoRaWAN CO2 sensor for smart buildings. It measures carbon dioxide (CO₂, 0–5,000 ppm), temperature and relative humidity, and its green, amber and red indicator light shows occupants when a room needs ventilating.
Its data is sent over LoRaWAN for remote monitoring or integration into a building management system (BMS). VISTA RISE runs for up to 10 years on a replaceable CR123 lithium battery, operates on the EU868 LoRaWAN frequency plan used in the UK and Ireland, and is CE and UKCA marked.
VISTA RISE measures three parameters:
- Carbon dioxide (CO₂): 0 to 5,000 ppm, accuracy ±(50 ppm + 3 % of reading), measured every 5 minutes
- Temperature: -30 °C to +70 °C, accuracy ±0.2 °C
- Relative humidity: 0 to 100 % RH, accuracy ±2 % RH
In the UK, HSE guidance states that CO₂ levels consistently higher than 1,500 ppm in an occupied room indicate poor ventilation and that action should be taken to improve it. As a reference point, about 1,000 ppm corresponds to roughly 10 litres of fresh air per second per person. For schools in England, BB101 sets CO₂ criteria for teaching spaces, such as a daily average below 1,500 ppm in naturally ventilated classrooms.
VISTA RISE measures CO₂ from 0 to 5,000 ppm, so rooms can be monitored against these benchmarks. CO₂ is an indicator of ventilation rather than a measure of every indoor air pollutant, and the sensor alone does not demonstrate compliance with building or ventilation requirements.
The VISTA RISE indicator light changes colour with the measured CO₂ level: green when the air is being renewed well, amber when ventilation should be considered, and red when it is time to ventilate the room. Indicator light settings can be adjusted by NFC from a smartphone to suit the building.
Yes. VISTA RISE (references X450LS in white and X450LS_BCK in black) uses the EU868 LoRaWAN frequency plan (863–870 MHz), which is the plan used for LoRaWAN in the United Kingdom and Ireland. It can connect to a private LoRaWAN gateway installed on site or to a LoRaWAN network that covers the building.
The sensor is CE and UKCA marked.
Yes. VISTA RISE transmits its measurements over LoRaWAN. Through a compatible infrastructure – such as a Nexelec MASTER PRO or MASTER CORE LoRaWAN-to-BACnet gateway – the data can be integrated into the BMS as BACnet/IP points to support the monitoring and control of ventilation, heating and air conditioning.
The data can also be used in the NAVIXIS platform, which provides an API and webhooks for third-party systems.
A standalone CO₂ monitor only shows its reading in the room. A LoRaWAN CO2 sensor such as VISTA RISE also shows a local traffic-light indication, but sends its measurements wirelessly so that CO₂, temperature and humidity can be centralised for every room, stored as history, used for threshold alerts and passed to the building management system.
LoRaWAN is designed for long range and very low power: its signal reaches through walls and floors, sensors do not need to join the building’s Wi-Fi network, and VISTA RISE can run for up to 10 years on one battery.
No. VISTA RISE runs on a lithium battery and communicates wirelessly over LoRaWAN, so no power or communication cabling is needed at the sensor. A LoRaWAN infrastructure (gateway and network server) is required to collect its data remotely.
VISTA RISE is wall-mounted with screws and wall plugs or with the supplied adhesive pad. Its lockable base with anti-theft screws and its tamper detection keep the installation secure. An instant measurement, triggered when the sensor is clipped onto its base, lets you check straight away that it is working.
VISTA RISE is powered by one replaceable CR123 lithium battery and can run for up to 10 years. Actual battery life depends on the settings (measurement and transmission intervals), network conditions and use; it is not guaranteed.
The L2D1 (Link to Device) radio link is a wireless communication technology that lets two compatible Nexelec devices communicate directly with each other, without a gateway or a LoRaWAN network.
It enables local, device-to-device (D2D) data exchange, in particular to simplify how devices are paired and operate together within a connected building.
This technology provides direct communication with a long radio range, which simplifies installation and reduces dependence on the network infrastructure.
Yes. VISTA RISE supports FUOTA V2 (Firmware Update Over The Air), a mechanism standardised by the LoRa Alliance. When updates are made available, fixes, security patches and improvements can be deployed remotely over a compatible LoRaWAN infrastructure, without visiting each sensor.
VISTA RISE measures CO2, temperature and humidity. VISTA WAVE adds PIR presence and light level measurement, making it a 5-in-1 indoor environmental sensor. Both support remote data collection over LoRaWAN. BMS integration requires a compatible gateway and an appropriate system integration.
* Battery life is not guaranteed and may vary depending on the product’s settings and usage.
